Key Advantages of the QMX8025S

1. Compact but Powerful
   Despite its smaller footprint and lighter weight (7000kg) compared to larger models, the QMX8025S maintains industrial-grade performance.

2. High Precision Multi-Process Integration
   The machine combines jump milling, continuous milling, and sanding, reducing transfer times and ensuring consistent edge finishing.

3. Wide Material Compatibility
   Handles a machining width range of 300 to 2500mm, suitable for various wood-based panels, doors, furniture components, and engineered boards.

4. Fast and Adjustable Feed Speed
   With a feeding speed up to 36 m/min, it supports both high-output production and precision control for delicate workpieces.

5. Variable Frequency Polishing Head
   Polishing speed up to 1400 r/min with frequency conversion, adaptable to different material textures and finishing requirements.

6. Energy-Efficient Motor System
   Motor options between 33.76–36.96 kW help users optimize energy consumption based on production needs.

7. Excellent Dust Extraction Compatibility
   Equipped with 8 large suction ports (Φ120mm) for integration into factory-level vacuum systems, promoting cleaner operation.

8. Flexible Customization Options
   Offers servo motor selection for pressing belt drive and adjustable spacing (500mm/1000mm between feed blocks), suitable for both standard and special production lines.

Ideal For

• Panel furniture factories

• Wooden door manufacturers

• Decorative board and veneer processors

• OEM component suppliers in home furnishings
